Dichroic Glass

Dichroic Coated Glass for Architectural Panels

Custom dichroic coated glass panels selected by color samples, viewing conditions, substrate and fabrication requirements.

Size or grade not decided yet? Describe your application to start. Ask a Glass Specialist

Material Ultra-Clear Low-Iron Float Glass, Premium Clear Float Glass
Size 1220mm / 915mm 1220mm / 1830mm 2440mm / 1830mm 3660mm / 2440mm 3300mm / 2140mm Customizable
MOQ Minimum quantity is confirmed for the selected grade, dimensions and processing route.
Delivery 7-15 Days
For a faster quote Share size, thickness, quantity, application, edge processing, and drawings or photos if available.

Quick Specs

Optical effect Angle-dependent reflected / transmitted colors
Coating route Multiple thin-film inorganic interference layers
Substrate Low-iron clear / standard clear float glass
Color combinations Examples: blue/magenta, orange/cyan, green/purple

Commercial Info

Production Capacity Quantity and production route confirmed for each order
Trade Terms Shipping terms confirmed in the quotation and contract
Payment Terms Payment schedule agreed for each order
Customization Service OEM/ODM, Custom Processing, Custom Dimensions, Edge Polishing, and Hole Drilling

B2B Product Profile

Materials

  • Ultra-Clear Low-Iron Float Glass
  • Premium Clear Float Glass

Commercial Info

MOQ: Minimum quantity is confirmed for the selected grade, dimensions and processing route.

Delivery: 7-15 Days

Packaging Types

  • Heavy-Duty Export Fumigation-Free Wooden Crates
  • A-Frame Metal Racks with Interlayer Anti-Mold Paper/Powder

Ships To

  • North America & South America
  • Europe & Middle East
  • Asia-Pacific & Worldwide

Applications

Building Exterior Facades & Architectural Curtain WallsOutdoor Landscape Art Installations & Scenic Spot StructuresLuxury Retail Storefronts, Displays, & Interior PartitionsCustom Glass Furniture (Coffee Tables, Display Cabinets, Decorative Panels)

Product Description

Product overview

North One Glass supplies dichroic coated glass for architectural panels, interiors, furniture and retail displays. The reflected and transmitted appearance changes with the lighting, background and viewing angle. Confirm a coated-glass sample or mock-up, substrate, thickness and final drawing together with the project environment. We review cutting, edgework, compatible processing and export packing for the selected panels. Review architectural dichroic glass and coated glass and dichroic film.

Reference values and acceptance: Published design targets and reference values are not signed acceptance tolerances. Final performance depends on substrate, coating construction, thickness and actual test conditions; customer acceptance criteria are confirmed against an approved sample and the relevant report.

Selection guide and application engineering

Dichroic appearance is an angular and environmental optical effect. Always review a real, documented sample at the project’s actual illuminants and angles (including daylight, artificial light and backlit conditions). Film type, orientation, heat treatment and lamination interlayers can change the color effect, so the approved physical sample should be the reference for production.

Typical applications

  • Retail and hospitality feature panels
  • Decorative glass partitions and display cabinets
  • Art installations, museum interaction features and optical accents
  • Architectural facade elements after safety, weathering and mock-up evaluation

Configuration and processing review

  • Approve actual color samples under the intended viewing angles and light sources.
  • Confirm color effect again after tempering, lamination or IGU construction.
  • For exterior installations, require the coating-specific environmental test package and project mock-up.

Processing, Samples and Delivery

North One Glass develops application-specific optical targets, evaluates samples and supplies the selected coated glass grade. Our own facility in China carries out cutting, precision edging, laser processing and tempering for compatible glass grades. Each order is checked against the drawing and processing requirements. Confirm dimensions, tolerances and the fabrication sequence before sample approval. Packing and the dispatch schedule are agreed for the panel size, quantity and destination.

Prepare Your Inquiry

Send your application, preferred grade or target performance, dimensions, thickness, quantity, edge and hole details, safety-processing needs, destination and sample schedule. A plain-language description is enough to start.

Review the related application · Quality and testing · Discuss a Dichroic Design Project

Full Specifications

Optical effectAngle-dependent reflected / transmitted colors
Coating routeMultiple thin-film inorganic interference layers
SubstrateLow-iron clear / standard clear float glass
Color combinationsExamples: blue/magenta, orange/cyan, green/purple
Spectral performanceCustom wavelength/color target by sample review
Size/processingSpecial-order larger panels, cut/edged/tempered/laminated if qualified

Packaging & Shipping

Packaging Details

Glass sheets are individually separated with anti-mold powder or protective paper and enclosed in export-grade, heavy-duty fumigation-free wooden crates secured with steel bands to eliminate movement and reduce the risk of breakage during sea freight.

FAQ

Why does dichroic glass change color with viewing angle?
Thin-film interference changes which wavelengths are reflected or transmitted as the optical angle changes; illumination spectrum also affects the visual result.
Can North One match a reference dichroic sample?
We analyze the target appearance and assess coating feasibility. An exact spectral or color match requires agreed tolerances and sample approval.
Can the glass be tempered, laminated or made into an IGU?
These routes may be available for qualified coating designs. Color, adhesion, stress and appearance should be confirmed on processed samples.
What is the maximum dichroic glass panel size?
Extra-long formats require a product-specific review of coating-line compatibility, secondary fabrication, lifting, shipping and sample appearance.
How is dichroic glass priced?
By actual coating design, substrate, thickness, usable sheet yield, secondary processing, quantity, packing and shipping terms.
What should I send for custom dichroic coated glass?
Send the color reference, sample or mock-up requirement, lighting and viewing conditions, substrate, thickness, finished dimensions, processing drawing, quantity and destination.

After-Sales Service

20-year quality warranty against coating peeling, fading, and edge corrosion under standard outdoor exposure conditions. Dedicated technical assistance provided for deep processing and site installation.
Technical documentation

Technical data & quality evidence

Follow the selected model from its technical data to measurement conditions, supporting records and applicable quality terms.

01

TDS & measurement methods

Measurement Methods & Data Interpretation
02

Test reports

Request the report for your selected grade, construction and test scope.

Request a product-specific report →
03

Raw data & spectral curves

Request available measurement data with the wavelength range, angle and sample construction.

Request measurement data →
04

Warranty & quality policy

Review the agreed product scope, acceptance basis and after-sales process for your project.

Warranty & Quality Policy →
Browse the technical document library →
